Full Body Red Light Therapy RH Full Body Red Light Panel
📦 Order now, receive it between
Choose options
Bring professional-grade red and near-infrared light therapy into your wellness space with the RH Full Body Red Light Panel. Designed for extensive full-body coverage, this large-format panel features 840 premium LEDs, a durable aluminum alloy housing, and an advanced cooling system for reliable operation during regular wellness sessions.
The RH Full Body panel offers flexible control over red and near-infrared light output, along with adjustable timers, dimming, and pulse settings. Available in 5-waveband and 7-waveband configurations, it is suitable for home wellness rooms, fitness facilities, spas, recovery centers, clinics, and other professional environments.
Large-Format Full Body Coverage
- 840 Premium LEDs: A large LED array provides broad and consistent light coverage across the body.
- Full Body Design: The oversized panel is designed for extensive-area light therapy while maintaining a relatively slim profile.
- 30° Beam Angle: Focuses light toward the intended treatment area.
- Protective Acrylic Front: Helps shield the LED array from dust, scratches, and everyday wear.
5-Waveband & 7-Waveband Configurations
The RH Full Body is available with either a 5-waveband or 7-waveband LED configuration, providing flexibility for different light therapy preferences.
5-Waveband Configuration
- 630nm: 84 LEDs
- 660nm: 336 LEDs
- 810nm: 48 LEDs
- 830nm: 36 LEDs
- 850nm: 336 LEDs
7-Waveband Configuration
- 480nm: 24 LEDs
- 630nm: 138 LEDs
- 660nm: 198 LEDs
- 810nm: 78 LEDs
- 830nm: 174 LEDs
- 850nm: 192 LEDs
- 940nm: 36 LEDs
Adjustable Light Therapy Controls
- Independent Red & NIR Control: Adjust red and near-infrared light output independently.
- Adjustable Timer: Choose from 5, 10, 15, 20, 25, or 30-minute sessions, or select a customizable 0-30 minute setting.
- Adjustable Dimming: Select 20%, 40%, 60%, 80%, or 100% output, or use the adjustable 0-100% range.
- Pulse Mode: Preset frequencies include 10, 40, 73, 146, 293, and 587 Hz, with an adjustable range up to 10,000 Hz.
- Multiple Control Options: Operate the panel using touch key controls or an optional Intelligent HD color touchscreen.
- Wireless Synchronization: Compatible panels can be wirelessly synchronized for expanded setups.
Durable Construction & Cooling System
- Premium Aluminum Alloy Housing: Provides a durable and lightweight structural enclosure.
- Patented Cooling System: Designed to help maintain consistent operating temperatures during use.
- Modular Internal Design: Simplifies servicing and maintenance when needed.
- Gold Wire & Copper Holder Construction: LED components are designed for long-term durability.
- Flicker-Free Operation: Designed for consistent light output without visible flickering.
Technical Specifications
| Model | RH Full Body |
| LED Quantity | 840 LEDs |
| Available Waveband Options | 5-Waveband or 7-Waveband |
| 5-Waveband | 630nm, 660nm, 810nm, 830nm, 850nm |
| 7-Waveband | 480nm, 630nm, 660nm, 810nm, 830nm, 850nm, 940nm |
| Frame Material | Aluminum Alloy |
| Input Voltage | 100-240 VAC, 50/60 Hz |
| Rated Power | 4200W |
| Power Consumption | 1092W |
| Irradiance at 6 Inches | 154 mW/cm² |
| Irradiance at 12 Inches | 141 mW/cm² |
| Irradiance at 18 Inches | 124 mW/cm² |
| Irradiance at 24 Inches | 108 mW/cm² |
| Lens Beam Angle | 30° |
| EMF | 0 μT at 3 inches |
| Operation | Flicker-Free |
| Expected LED Lifespan | Up to 100,000 hours |
| Timer | 5-30 minutes or adjustable 0-30 minutes |
| Dimmer | 20%, 40%, 60%, 80%, 100% or adjustable 0-100% |
| Pulse Frequency | 10-587 Hz preset options or adjustable 0-10,000 Hz |
| Dimensions | 1717 × 415 × 71 mm / 67.6 × 16.3 × 2.79 inches |
| Weight | 37 kg / 81.6 lbs |
| Warranty | 3-Year Limited Warranty |
What's Included
- 1 × RH Full Body Red Light Panel
- 1 × Integrated Control System
- 1 × User Documentation
Ideal Applications
The RH Full Body Red Light Panel is designed for users seeking extensive-area red and near-infrared light exposure in home wellness rooms, fitness facilities, spas, recovery centers, clinics, and other professional environments. Its large format provides broad full-body coverage while maintaining a compact wall-mounted profile.
Important Product Information
This product emits red and near-infrared light and is intended for light therapy applications. It is not intended to diagnose, treat, cure, or prevent any disease. Always operate the panel according to the manufacturer's instructions. Product specifications and available configurations are subject to change without prior notice.
